Rockwell Automation Publication 1734-UM018D-EN-E - September 2017 17
Install Your 1734 POINT I/O EtherNet/IP Adapter Chapter 2
Wire the Adapter
The POINT I/O adapter uses RJ45 EtherNet/IP connectors for its EtherNet/ IP
connection. Connect the cord set you selected for your module to the
appropriate port.
Wire a POINT I/O Adapter
Refer to the following illustration to wire the adapter.
ATTENTION: Do not connect 120/240V AC power to this supply. This
DC supply will be connected to the internal power bus.
02
0
Chas
C
V
NC
RJ45 EtherNet/IP
Connector
43264
Network address
thumbwheels
NC = No Connection
Chas Gnd = Chassis Ground
C = Common
V = Supply
This DC supply connects
to the internal power bus.
NC
V
NC
Chas
Gnd
V
0
4
2
6
Chas
Gnd
1
5
3
7
V DC
C
C
