34 Rockwell Automation Publication 1734-UM018D-EN-E - September 2017
Chapter 4 Configure the Adapter for Direct Connection in RSLogix 5000 or Logix Designer Software
5. Select the correct Revision, Chassis Type, and Slot number of the L63
controller, and the folder where you want to save the RSLogix 5000 file
(Create In). The Description is optional.
Note: RSLogix 5000 software Revision 18, and later, lets you enable
redundancy. To use redundancy in your system, check the Redundancy
Enabled checkbox in the Redundancy tab when using the said Revision or
later.
6. Click OK.
Configure the I/O Modules
You now add the POINT I/O modules to the controller’s I/O configuration
performing these procedures:
• Add the local 1756-ENBT Bridge module to the I/O configuration.
• Add the 1734-AENT/B adapter as a child of the 1756-ENBT module on
the Ethernet network.
• Add the POINT I/O modules as children of the AENT/B adapter.
Click the Help button on the configuration dialogs shown in this
section if you need assistance in selecting and setting the
parameters.
