Allen-Bradley 1734 User Manual

Rockwell Automation Publication 1734-UM018D-EN-E - September 2017 87
Specifications Appendix A
EtherNet Communication
The 1734-AENT adapter modules have the following EtherNet communication
specifications.
Environmental
Specifications
The 1734-AENT EtherNet/IP Adapter modules have the following
environmental specifications.
Input overvoltage protection Reverse polarity protected
POINTBus output, max 5V DC @ 1.0 A
Interruption Output voltage stays within specifications when input drops
out for 10 ms @ 10V with max load
Power Supply Specifications
Attributes Description
EtherNet Communication Specifications
Attributes Description
Ethernet communication rate 10/100 Mbits/s, half or full-duplex
Ethernet port 1
Ethernet network topologies
supported
Star, Tree
Ethernet connectors RJ-45, Category 5
Ethernet cable Category 5:
shielded or unshielded
Ethernet wire connections, max See Wire Size
on page 86
Environmental Specifications
Attributes Description
Temperature, operating IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-20...55 °C (-4...131 °F)
Temperature, nonoperating IEC60068-2-1 (Test Ab, Unpackaged Nonoperating Cold)
IEC60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat)
IEC60068-2-14 (Test Na, Unpackaged Nonoperating
Thermal Shock):
-40...85 °C (-40...185 °F)
Temperature, surrounding air, max 55 °C (131 °F)
Relative humidity IEC 60068-2-30 (Test Db, Unpackaged Damp Heat):
5...95% non-condensing
Vibration IEC 60068-2-6 (Test Fc, Operating):
5 g @ 10...500 Hz
Shock, operating IEC60068-2-27 (Test Ea, Unpackaged Shock):
30 g
Shock, nonoperating IEC60068-2-27 (Test Ea, Unpackaged Shock):
50 g
