Allen-Bradley 1734 User Manual

Rockwell Automation Publication 1734-UM018D-EN-E - September 2017 81
Chapter 6
Troubleshoot the Adapter
This chapter describes the different status indicators available in the 1734
POINT I/O EtherNet/IP adapter and how to interpret these indicators to help
troubleshoot the module.
The following table lists where to find specific information
Interpret the Status
Indicators
The 1734 POINT I/O EtherNet/IP adapters have the following status
indicators:
• Module Status,
• Network Activity,
• Network Status
• POINTBus Status
• System Power
• Field Power
Topic Page
Interpret the Status Indicators 81
Status Indicators for POINT I/O Adapters 82
ATTENTION: You must only use Series C and above POINT I/O modules
with 1734-AENT EtherNet/IP Adapters. Series A or Series B POINT I/O
modules do not work with 1734-AENT EtherNet/IP Adapters (does not
apply to POINTGuard modules).
