Rockwell Automation Publication 1734-UM018D-EN-E - September 2017 31
Chapter
4
Configure the Adapter for Direct Connection
in RSLogix 5000 or Logix Designer Software
Overview
This chapter guides you through the steps required to configure your modules
using the RSLogix 5000 or Logix Designer
(1)
software.
In this example, a ControlLogix controller communicates with I/O modules via
the adapter using a direct connection.
The adapter makes a direct connection to each of the modules referenced by the
data. The modules presented in this chapter use RSLogix 5000 software, version
17, or later.
(1) From version 21 onwards, RSLogix 5000 is known as Logix Designer.
Topic Page
Set Up the Hardware 32
Create the Example Application 33
Configure the I/O Modules 34
Add the Local EtherNet/IP Bridge to the I/O Configuration 35
Add the POINT I/O Adapter to the I/O Configuration 38
Add the POINT I/O Modules to the I/O Configuration 41
Edit the Controller Tags 47
Create the Ladder Program 48
Download the Program to the Controller 48
Verify the Module Chassis Size 49
Configure the Adapter with Fixed IP Address 52
Recover From an Overloaded Adapter 53
Chapter Summary 53
ATTENTION: You must only use Series C and above POINT I/O modules
with 1734-AENT EtherNet/IP Adapters. Series A or Series B POINT I/O
modules do not work with 1734-AENT EtherNet/IP Adapters (does not
apply to POINTGuard modules).
