File Logic Instructions
Chapter 16
162
This output instruction operates on the contents of two data files A and B
and places the result of the operation AND in a third File R.
The logic operation AND compares each bit in File A to the corresponding
bit in File B. If the compared bits are both 1, a 1 is stored in the
corresponding bit location in File R. If the bits are other than both 1, a 0 is
stored in the corresponding bit in File R (Table 16.A).
Table 16.A
Truth
Table for Logical AND
Bit In File A Bit In File B Bit In File R
1
1
0
0
1
0
1
0
1
0
0
0
Instruction Overview:
Output Instruction
Key sequence [FILE] 14
Requires 6 words of user program
Can operate in incremental, distributed complete or complete mode
Counter is internally indexed by the instruction
Programming FiletoFile AND Instruction
WARNING: The counter address for the File-to-File AND
instruction should be reserved for that instruction. Do
not manipulate the counter accumulated or preset values.
Inadvertent changes to these could result in unpredictable or
hazardous machine operation or a run-time error. Damage to
equipment and/or personal injury could result.
To program a File-to-File AND instruction, press keys [FILE] 14. A
display represented by Figure 16.2 will appear.
16.1.1
FiletoFile AND
