Introduction to Programming
Chapter 4
416
Table 4.B
Help
Directories
Function Mode Key Sequence Description
Help Directory Any [HELP] Displays a list of the keys that are used with the [HELP]
key to obtain further directories.
Control Function Directory Any [SEARCH] [HELP] Provides a list of all control functions that use the
[SEARCH] key.
Record Function Directory Any [RECORD] [HELP] Provides a list of functions that use the [RECORD] key.
Clear Memory Directory Program [CLEAR MEMORY] [HELP] Provides a list of all functions that use the [CLEAR
MEMORY] key.
Data Monitor Directory Any [DISPLAY] [HELP] Provides the choice of Data Monitor displays accessed by
the [DISPLAY] key.
File Instruction Directory Any [FILE] [HELP] Provides a list of all instructions that use the [FILE] key.
Sequencer Instruction
Directory
Any [SEQ] [HELP]
Block Transfer Directory Any [BLOCK XFER] [HELP] Provides a list of all instructions that use the [BLOCK
XFER] key.
Shift Register Any [SHIFT REG] [HELP] Provides a list of all instructions that use the [SHIFT REG]
key.
All Directories Any [CANCEL COMMAND] To terminate.
The industrial terminal can be used to search the user program for:
Specific instruction and specific word addresses
First or last instruction in a rung
Single rung display
Incomplete rung
First and last rung and user boundaries
Remote Mode Select
Specific Instructions and Specific Word Addresses
Any instruction in user program can be located by pressing
[SEARCH][Key sequence of instruction][Key sequence of address]. Enter
leading zeros before the address, if necessary. Block instruction can be
searched for by using the counter address or the first entered address in the
block.
The procedures for finding a specific instruction or address are similar
(Table 4.C). All addresses (excluding those associated with Examine On
and Examine Off instructions and those contained within files) can be
located by pressing [SEARCH]8 [Key sequence of address]. The address
4.4.3
Searching
