Rockwell Automation Publication 20A-UM001N-EN-P - July 2013 85
Troubleshooting Chapter 2
Table 4 - Alarm Cross Reference
Testpoint Codes and
Functions
Table 5 - Testpoint Codes and Functions
No.
(1)
(1) Alarm numbers not listed are reserved for future use.
Alarm No.
(1)
Alarm No.
(1)
Alarm
1 Precharge Active 12 Motor Thermistor 23 MaxFreq Conflict
2 UnderVoltage 13 In Phase Loss 24 VHz Neg Slope
3 Power Loss 14 Load Loss 25 IR Volts Range
4 Start At PowerUp 15 Ground Warn 26 FluxAmpsRef Rang
5 Analog in Loss 17 Dig In ConflictA 27 Speed Ref Cflct
6 IntDBRes OvrHeat 18 Dig In ConflictB 28 Ixo Vlt Rang
8 Drive OL Level 1 19 Dig In ConflictC 29 Sleep Config
9 Drive OL Level 2 20 Bipolar Conflict 30 TB Man Ref Cflct
10 Decel Inhibit 21 Motor Type Cflct 31 PTC Conflict
11 Waking 22 NP Hz Conflict 51 UserSet Conflict
Code Selected in
[Testpoint x Sel]
Function Whose Value is Displayed in
[Testpoint x Data]
1 DPI Error Status
2 Heatsink Temperature
3 Active Current Limit
4 Active PWM Frequency
5 Lifetime MegaWatt Hours
(1)
(1) Use the equation below to calculate total Lifetime MegaWatt Hours.
6 Lifetime Run Time
7 Lifetime Powered Up Time
8 Lifetime Power Cycles
9 Life MegaWatt Hours Fraction
(1)
10 Life MegaWatt Hours Fraction Units
(1)
11…99 Reserved for Factory Use
Value of Code 9
Value of Code 10
---------------------------------
0.1×
⎝⎠
⎛⎞
Value of Code 5+ Total Lifetime MegaWatt Hours=
