Chapter 1 Programming and Parameters
* These parameters are available only when parameter 053 [Motor Cntl Sel] is set to option 2 or 3.
** These parameters are available only when parameter 053 [Motor Cntl Sel] is set to option 4.
3.x
Firmware revision 3.002 and later.
Monitor File (file A)
Inputs and Outputs Analog Inputs Anlg In Config 320
Anlg In Sqr Root 321
Analog In 1 Hi 322
Analog In 1 Lo 323
Analog In 1 Loss 324
Analog In 2 Hi 325
Analog In 2 Lo 326
Analog In 2 Loss 327
Analog Outputs Anlg Out Config 340
Anlg Out Absolut 341
Analog Out1 Sel 342
Analog Out1 Hi 343
Analog Out1 Lo 344
Anlg Out Scale 354
Anlg Out1 Setpt 377
Digital Inputs Digital In1…6 Sel 361…366 DigIn DataLogic 411
Digital Outputs Dig Out Setpt 379
Digital Out1 Sel 380
Dig Out1 Level 381
Dig Out1 OnTime 382
Dig Out1 OffTime 383
Digital Out2 Sel 384
Dig Out2 Level 385
Dig Out2 OnTime 386
Dig Out2 OffTime 387
Applications
3.x
Fiber Functions
3.x
Fiber Control 620
3.x
Fiber Status 621
3.x
Sync Time 622
3.x
Traverse Inc 623
3.x
Traverse Dec 624
3.x
Max Traverse 625
3.x
P Jump 626
3.x
File Group Parameters
Inputs & Outputs
File J
Applications
File K
File A Group No.
Parameter Name and Description
See page 14 for symbol descriptions
Values
Related
MONITOR (file A)
Metering
001 [Output Freq]
Output frequency present at T1, T2, and T3
(U, V, and W)
Default:
Min/Max:
Units:
Read Only
±[Maximum Freq]
0.1 Hz
002 [Commanded Freq]
Value of the active frequency command.
Default:
Min/Max:
Units:
Read Only
±[Maximum Speed]
0.1 Hz
213
003 [Output Current]
The total output current present at
T1, T2, and T3 (U, V, and W).
Default:
Min/Max:
Units:
Read Only
0.0/Drive Rated Amps × 2
0.1 Amps
0.01 Amps
004 [Torque Current]
The amount of current that is in phase with the
fundamental voltage component.
Default:
Min/Max:
Units:
Read Only
Drive Rating × –2/+2
0.1 Amps
0.01 Amps
005 [Flux Current]
The amount of current that is out of phase with
the fundamental voltage component.
Default:
Min/Max:
Units:
Read Only
Drive Rating × –2/+2
0.1 Amps
0.01 Amps
063
006 [Output Voltage]
Output voltage present at terminals
T1, T2, and T3 (U, V, and W).
Default:
Min/Max:
Units:
Read Only
0.0/Drive Rated Volts
0.1 VAC
054
202
007 [Output Power]
Output power present at T1, T2, and T3
(U, V, and W). The output power is a calculated
value, dependent on autotune values.
Read Only
0.0/Drive Rated kW × 2
0.1 kW
0.01 kW
008 [Output Powr Fctr]
Output power factor.
Default:
Min/Max:
Units:
Read Only
0.00/1.00
0.01
009 [Elapsed MWh]
Accumulated output energy of the drive.
Default:
Min/Max:
Units:
Read Only
0.0/429496729.5 MWh
0.1 MWh
32
E C
E C
32
E C
E C
32
E C
E C
32
E C
E C
32
