Allen-Bradley PowerFlex 70 User Manual

54 Rockwell Automation Publication 20A-UM001N-EN-P - July 2013
Chapter 1 Programming and Parameters
UTILITY (file E)
Diagnostics
213 [Speed Ref Source]
Displays the source of the speed reference to
the drive.
(1)
Displays after Start is pressed.
(2)
Only Enhanced Control Drives.
Default:
Options: 0
1
2
3…7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23, 24
25
26
27…2
9
30
Read Only
“PI Output”
(1)
“Analog In 1”
“Analog In 2”
“Reserved”
“Encoder”
“MOP Level”
“Reserved”
“Preset Spd1”
“Preset Spd2”
“Preset Spd3”
“Preset Spd4”
“Preset Spd5”
“Preset Spd6”
“Preset Spd7”
“DPI Port 1”
“DPI Port 2”
“DPI Port 3”
“Reserved”
“DPI Port 5”
“Reserved”
“Scale Block1”
“Scale Block2”
“Reserved”
“HighRes Ref”
(2)
002
090
093
096
101
214 [Start Inhibits]
Displays the inputs currently preventing the drive from
starting.
Read Only
243
361…
366
215 [Last Stop Source]
Displays the source that initiated the most
recent stop sequence. The display is cleared (set
to 0) during the next start sequence.
Default:
Options: 0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Read Only
“Pwr Removed”
“DPI Port 1”
“DPI Port 2”
“DPI Port 3”
“Reserved”
“DPI Port 5”
“Reserved”
“Digital In”
“Fault”
“Not Enabled”
“Sleep”
“Jo g”
“Autotune”
“Precharge”
“Safe Off”
361…
366
File E Group No.
Parameter Name and Description
See page 14 for symbol descriptions
Values
Related
000000000000x0xx
10 01234567891112131415
1 = Inhibit True
0 = Inhibit False
x = Reserved
Bit #
Fault
Type 2 Alarm
Enable
DC Bus Pchrg
Stop Assertd
Params Reset
StartUp Actv
Safe Off
(1)
Digital In
DPI Port 1
DPI Port 2
DPI Port 3
Reserved
DPI Port 5
Nibble 1Nibble 2Nibble 3Nibble 4
(1)
Enhanced firmware 3.002 & later.
E C
E C
E C v3
