Allen-Bradley PowerFlex 70 User Manual

Rockwell Automation Publication 20A-UM001N-EN-P - July 2013 55
Programming and Parameters Chapter 1
UTILITY (file E)
Diagnostics
216 [Dig In Status]
Status of the digital inputs.
Read Only
361…
366
411
217 [Dig Out Status]
Status of the digital outputs.
Read Only
380…
384
218 [Drive Temp]
Present operating temperature of the drive
power section.
For heatsink temperature, refer to P234
[Testpoint 1 Sel].
Default:
Min/Max:
Units:
Read Only
±100 degC
0.0/100.0%
1.0 degC
0.1%
219 [Drive OL Count]
Accumulated percentage of drive overload.
Continuously operating the drive over 100% of
its rating increases this value to 100% and
cause a drive fault or foldback depending on
the setting of [Drive OL Mode].
Default:
Min/Max:
Units:
Read Only
0.0/100.0%
0.1%
150
220 [Motor OL Count]
Accumulated percentage of motor overload.
Continuously operating the motor over 100% of
the motor overload setting increases this value
to 100% and cause a drive fault.
Default:
Min/Max:
Units:
Read Only
0.0/100.0%
0.1%
047
048
221 [Mtr OL Trip Time]
Amount of time before a drive Overload
fault(f64) occurs if the load condition remains
constant. A value of 99999 means that the drive
is operating under the overload level.
Default:
Min/Max:
Units:
Read Only
0/99999
1
220
File E Group No.
Parameter Name and Description
See page 14 for symbol descriptions
Values
Related
000000xx000000xx
10 01234567891112131415
1=Input Present
0=Input Not Present
x =Reserved
Bit #
Digital In1
Digital In2
Digital In3
Digital In4
Digital In5
Digital In6
In1 DLogRslt
(1)
In2 DLogRslt
(1)
In3 DLogRslt
(1)
In4 DLogRslt
(1)
In5 DLogRslt
(1)
In6 DLogRslt
(1)
Nibble 1Nibble 2Nibble 3Nibble 4
(1)
Enhanced firmware 2.001 & later.
0xx 0xxxxxxxxxxxx
10 01234567891112131415
1=Output Energized
0=Output De-energized
x =Reserved
Bit #
Digital Out1
Digital Out2
Nibble 1Nibble 2Nibble 3Nibble 4
E C
E C
E C v3
