Introduction
15
MVP-5200i Modero® ViewPoint® Touch Panel with Intercom - Instruction Manual
Memory
The MVP-5200i comes with 128MB of Mobile DDRAM memory and 256 MB NAND Flash memory. Neither may be upgraded.
MVP-5200i Specifications (Cont.)
Dot/pixel Pitch: FG5966-01 & FG5966-02: 0.23 mm
FG5966-03 & FG5966-04: 0.135 x 0.135 mm
Screen Resolution: • 800 x 480 pixels (HV) @ 60 Hz frame frequency
Viewing Angles: FG5966-01 & FG5966-02:
• Vertical: + 40° (up from center) and - 80° (down from center)
• Horizontal: + 60° (left from center) and - 60° (right from center)
FG5966-03 & FG5966-04:
• Vertical: + 50° (up from center) and - 70° (down from center)
• Horizontal: + 70° (left from center) and - 70° (right from center)
External Components
Connector: 5-pin Mini-USB connector used for audio output to USB headphones,
programming, firmware updates, and touch panel file transfer between the PC and the target panel.
Note: When connecting the panel to PC using a CC-USB (or compatible) cable, be sure to power the panel On
before attempting to connect the USB cable from the PC to the mini-USB port on the panel.
DC power port: 2.5 mm port to power the panel away from a Charging Station.
Stylus Slot: Slot where the included stylus is stored, located on the right side of the device.
Microphone: For use with the intercom feature.
• Frequency: 20 to 160,000 Hz
• S/N Ratio: More than 58 dB
Speaker: • 4Ohm
• 2 Watts 300Hz cutoff frequency
Audio Standards: • G.711 sound standard
•75dB SPL@1m
IR Emitters: Transmit IR over 20 feet (6.10 m) from the panel.
• IR emitters on G4 panels share the device address number of the panel.
• Transmits AMX fixed frequencies at 38KHz and 455KHz and user programmable frequencies from 20KHz to
1.5MHz
Operating/Storage
Environment
• Operating Temperature: 0° C (32° F) to 40° C (104° F)
• Operating Humidity: 20% - 85% RH
• Storage Temperature: -20° C (-4° F) to 60° C (140° F)
• Storage Humidity: 5% - 85% RH
Included Accessories: • MVP-5200i Installation Guide (93-5966-01)
•PS3.0 Power Supply (FG423-30)
• MVP-STYLUS-52 (pre-installed onto the right side of the unit)
(FG5966-06XX)
Other AMX Equipment: • MVP-TCS-52 Table Charging Station (FG5966-1X)
• MVP-WCS-52 Wall Charging Station (FG5966-1X)
• CSG-500 Gateway for 50 Users (FG2182-01)
• CSG-544 Gateway for 50 Users, 4 analog phone input ports, 4 PSTN output ports (FG2182-02)
• CSG-580 Gateway for 50 Users, 8 PSTN Lines (FG2182-03)
• MVP-STYLUS-52 Replacement Stylus, Pack of 3 (FG5966-30-xx)
• CC-USB USB Programming Cable (FG10-5965)
• CC-HPADAPTER Headphone Adapter Cable (FG5966-23)
• NXA-WAP1000 Smart Wireless Access Point (FG2255-51/53)
