UPDATES ENGINE C364M

4 - 11

ENGINE C364M

4.4. SECTOR GEAR

4.4.1. DISASSEMBLY OF THE SECTOR GEAR AND

PINION

• Remove the pedal starter pinion.

• Remove the pedal starter lever, then remove the circlip

and ring seal. Ease off the sector gear and spring with

a mallet.

N.B.

The spring is kept loaded by the sector gear. Be careful,

since this could cause an accident.
