ENGINE
3 - 33
ENGINES C361M / C364M
3.6.2. REPLACEMENT OF THE CYLINDER AND PIS-
TON
• Insert the circlips on the piston. Make sure their
notches are in the right position.
• Insert the roller lane in the foot of the con rod.
• Mount the piston and the pin on the small end of the
con rod. Position the piston with the arrow pointing to-
wards the exhaust aperture.
• Insert the pin retaining ring in the specific tool with the
opening indicated on the tool.
