ENGINE
3 - 31
ENGINES C361M / C364M
3.6. CYLINDER AND PISTON
3.6.1. REMOVAL OF THE CYLINDER AND PISTON
• Remove the cylinder with its gasket. Support the piston
to make sure it is not damaged.
• Protect the cylinder seat and then use the specific tool
to remove the two pin retainers from the cavities in the
piston.
• Use an appropriate punch to push out the pin. Remove
the piston.
• Next remove the roller lane from the small end of the
con rod.
