ENGINE
3 - 19
ENGINES C361M / C364M
3.4. CLUTCH ON THE BENCH
3.4.1. SEPARATION CLUTH - DRIVING PULLEY
• Use the specific tool to position the clutch - moving pul-
ley assembly.
• Apply force to the central bolt. Do not overtighten it as
this could damage the tool.
• Remove the clutch locking nut.
•
Slacken the central bolt. Take the strain off the driven
pulleys assembly and separate its components.
