ENGINE
3 - 45
ENGINES C361M / C364M
3.10. REAR HUB
3.10.1. DISASSEMBLY OF REAR HUB AND WHEEL
BEARING
• Drain the oil from the hub and remove the mounting
bolts.
• Remove the hub cover complete with the driven pulley
shaft by means of light taps with a mallet.
• Remove the idler and the wheel shaft complete with
the gearing. Pay attention to the shim adjustments
when removing the idler.
