ENGINE
3 - 47
ENGINES C361M / C364M
3.10.2. DISASSEMBLY OF DRIVEN PULLEY SHAFT
• Remove the circlip from inside the cover.
• Position the specific pipe on the inner race of the bear-
ing and on the side of the pulley shaft toothing. Use a
press to force out the driven pulley shaft.
• Remove the outer oil shield.
• Remove the two centring pins and place the cover on a
flat surface.
• Position the specific tool on the inner race of the bear-
ing and force the bearing out with a press.
