ENGINE
3 - 36
ENGINES C361M / C364M
3.6.4. CYLINDER/PISTON MATING CATEGORIES
MATING CATEGORIES
PART SIZE
SYMBOL CYLINDER "E" PISTON "C"
ASSEMBLY
PLAY "A"
M 39,990÷39,997 39,943÷39,950
Cylinder
Ø 40
-0,01
+0,018
N 39,997÷40,004 39,950÷39,957
O 40,004÷40,011 39,957÷39,964
Piston
Ø 40
-0,02
-0,057
P 40,011÷40,018 39,964÷39,971
M1 40,19÷40,197 40,143 ÷ 40,15
Cylinder 1a Over-
size
Ø 40,2
-0,01
+0,018
N1 40,197÷40,204 40,15 ÷ 40,157
O1 40,204÷40,211 40,157 ÷ 40,164
Piston 1a
Oversize
Ø 40,2
-0,029
-0,057
P1 40,211÷40,218 40,164 ÷ 40,171
M2 40,39÷40,397 40,343 ÷ 40,35
Cylinder 2a Over-
size
Ø 40,4
-0,01
+0,018
N2 40,397÷40,404 40,35 ÷ 40,357
O2 40,404÷40,411 40,357 ÷ 40,364
Piston 2a
Oversize
Ø 40,4
-0,029
-0,057
P2 40,411÷40,418 40,364 ÷ 40,371
0,040
0,054
