APRILIA C364M User Manual

UPDATES ENGINE C216M
5 - 5
ENGINE C216M
5.2.2. TIGHTENING TORQUE TABLE
DESCRIPTION
QUANTITY
TIGHTENING
TORQUE
(Nm)
Transmission cover screw 12 12 ÷ 13
Drive pulley nut 1 40 ÷ 44
Clutch housing nut 1 40 ÷ 44
Clutch nut 1 55 ÷ 60
Cylinder head nuts 4 10 ÷ 11
Spark plug fastener 1 11 ÷ 14
Injection head securing screw 2 3 ÷ 4
Flywheel nut 1 40 ÷ 44
Case fastening screw 8 12 ÷ 13
Hub cover screw 5 11 ÷ 13
Throttle body manifold screw 2 7 ÷ 8
Air compressor screw 4 3 ÷ 4
FUEL SYSTEM
CYLINDER HEAD
FLYWHEEL
CRANKCASE
REAR HUB
TRANSMISSION COVER
ENGINE
DRIVE PULLEY
CLUTCH
