ENGINE
3 - 50
ENGINES C361M / C364M
3.10.5. EPLACEMENT OF REAR HUB AND WHEEL
BEARING
• Use a heat gun to heat the half-casing on the transmis-
sion side.
• Lubricate the outer plate. Use a mallet to insert the
bearing with the special adapter.
• Use the adapter and its handle to replace the circlip
and oil shield.
• Replace the idler. Pay attention to the two shim ad-
justments.
• Apply Loctite for surfaces on the hub cover. Replace
the hub complete with the driven pulley shaft. Insert the
bolts and tighten them to the correct torque value.
N.B. Remove the residues of the previous gasket from the
hub cover and half-casing contact surfaces before fitting the
new gasket.
