GENERAL TECHNICAL INFORMATION
2 - 5
ENGINE C361M / C364M
2.1.3. TIGHTENING TORQUE SETTINGS
NAME
QUANTITY
TIGHTENING
TORQUE
(Nm)
ENGINE
TRANSMISSION COVER
TRANSMISSION COVER BOLT 12 12 ÷ 13
DRIVING PULLEY
DRIVING PULLEY NUT 1 40 ÷ 44
CLUTCH CASE NUT 1 40 ÷ 44
CLUTCH
CLUTCH NUT 1 55 ÷ 60
ENGINE HEAD
ENGINE HEAD BOLT 4 10 ÷ 11
COOLANT OUTLET UNION ATTACHMENT BOLT 2 3 ÷ 4
TEMPERATURE SENSOR 1 18 ÷ 22
PLUG ATTACHMENT 1 11 ÷ 14
ATTACHMENT BOLT INJECTION HEAD 2 3 ÷ 4
FLYWHEEL
FLYWHEEL NUT 1 40 ÷ 44
ENGINE CASE
CASE CLOSING BOLT 8 12 ÷ 13
REAR HUB
HUB COVER BOLT 5 11 ÷ 13
FUEL SUPPLY SYSTEM
THROTTLE BODY MANIFOLD BOLT 2 7 ÷ 8
AIR COMPRESSOR BOLT 4 3 ÷ 4
