UPDATES ENGINE C364M
4 - 21
ENGINE C364M
4.7.2. DISMANTLING THE CARBURETTOR
• Loosen the clamp bolt and separate the carburettor
from the manifold.
• Unscrew the bolts and remove the protection, the
bracket and the choke.
• Unscrew the air-petrol dispenser cover and remove it.
Remove the spring and its cable retaining cup.
