Control panel
(All ATAG boiler range)
RESET
BACK OK
19°25/07/18 09:00
23.2º
75°45°
ECO AUTO
Press OK to enter Menu
1.4 bar
00 02 04 06 08 10 12 14 16 18 20 22 24
1
BC A
D E
Controller buttons
A Selector Wheel Turn the wheel left or right to scroll through available menu options
B OK button Press to select/confirm an item
C BACK button Press to go back one screen
D RESET button Press to reset a fault code
E Chimney sweep button Press to enter into service mode which button allows adjustment of high fire/low fire and CO2 settings
Controller display
1 DHW comfort or economy mode is active
11
Boiler status indicator, such as "Press OK to enter Menu", error messages and
other status information
2 DHW status symbol. A box around the tap symbol indicates DHW is in operation
3
Visual illustration of current hot water temperature. Scale changes as the set
temperature is changed
12 Heating supply setpoint
13 Outdoor temperature (if connected)
4 Internal room temperature (if present) 14 Time program
5 DHW set point temperature
15
Visual illustration of current central heating temperature. Scale changes as the
set temperature is changed
6 CH time program active
7 Flame Burner on
16
Central heating status symbol. A box around the radiator symbol indicates
central heating is in operation
8 Current date and time
9 Actual Power Level 17 Thermoregulation function enabled
10 Current central heating system water pressure
5 76 8 9 10 11 12 13
14
15
16
171
2
3
4
8
