SmartROC T45-10 3 Controls and Instruments
20
3.8 Operator'sEnvironmentControlPanel
PanelforOperator'sCabin
A Frontcabinworkinglights
B Rearcabinworkinglights
C Feedworkinglights
D Enginecompartmentlight
E Upperwindshieldwashers
F Upperwindshieldwiper(eachpressincreasesspeed)
