SmartROC T45-10 4 Operation
36
4.2.7CheckingbeforeUsingtheWinch
Thefollowingmustbecheckedbeforeeachuseofthewinch.
n
Checkthatthecable(A)isattachedcorrectlyintheconnectorsleeveandeye.The
cablemustruninlinewiththeeyeontheconnectorsleeve.
n
Checkthatthecablehasnotsustainedanydamage.
n
Checkthatthereareatleast4turnsremainingonthedrum.Thewinchmustneverbe
usedwithfewerthan4turnsremainingonthedrum.
4.2.8UsingtheWinchwhenTramming
WARNING
TippingRisk
Thetippingoverofamachinecancauseseriousinjuryordeath.
u Neverexceedthemaximumallowedinclinationanglesforthemachine.
u Nevercombineinclinationanglesfordownward/upward/lateraltramming.
u Neveroperatethedrillrigfromthedownside.
u Keepthewinchcablecontinuouslytaut.
WARNING
UnintentionalManeuvering
Cancauseseriousinjuryanddamagetoproperty.
u Alwayshaveanoverviewofthedrillrigandthewinchcontrolunit.
u Neveroperatethewinchcontrolunitfromthedrillrigwhenthewinchisbeingused.
u Alwaysdeactivatethewinchcontrolunitwhennotinuse.
Condition
p
Checksbeforeusingthewinchhavebeenperformed.
1.
Checkthatthetrackoscillationisunlocked.
2.
Checkthattheboomsystemisintransportposition.
