SmartROC T45-10 4 Operation
47
21.
Threadadrillbitontothelastdrillpipetofinishtheprocedure.
DANGER
RotatingParts
Thereisariskofseriousinjuryordeathasclothingcangetcaught
inthemachine.
u Stopthedrillrotationbeforeaddingadrillbit.
4.5 Drilling
4.5.1DrillingSettings
CalibratingtheLengthSensor
LengthSettingsMenu
Therigisfittedwithanabsolutepositionsensoranddoesnotusuallyneedcalibration.The
lengthsensorrequirescalibrationinthefollowingcases:
n Programloading
n Parameterloading
n The"Lengthsensornotcalibrated"symbolisshown
1.
Changeusertoservice(SE).
2.
Reversetherockdrilltothemechanicalstopwithdrillfeedorunthreading.
