Atlas Copco SmartROC T45--10 User Manual

SmartROC T45-10 5 Transport
57
5.4 BeforeTransportingtheLoadedDrillRig
WARNING
TippingRisk
Thetippingoverofamachinecancauseseriousinjuryordeath.
u Lockthetrackoscillationbeforehoistingthemachine.
u Adapttransportationequipmenttothedimensionsandweightofthemachine.
u Checkthatallhatchesareproperlylocked.
TransportPosition
Condition
p
Attachstrapsorchainstotheliftingeyesonthemachineandtransportvehicle.
1.
Extractthehydraulicjack.
2.
TrackoscillationcylinderstoLOCKEDposition.
3.
Supportthefeedbeamagainstthevehicletopreventoverloading.
4.
Switchoffthedieselengine.
5.
Strapthedrillrigsecurelytothevehicle.
