SmartROC T45-10 5 Transport
56
5.3 HoistingaDrillRig
WARNING
RiskofCrushing
Crushingcancauseseriouspersonalinjuryordeath.
u Useextremecautionwhenslingingandhoistingheavyobjects.
u Hoistingmusttakeplaceatthecenterofgravity.
u Onlyuseslingsthatareintactanddesignedfortheloadtheywillcarry.
u Fastenthestrapstoliftingeyes,ifavailable.
u Donotapproachasuspendedload..
Toachievemaximumdrillrigstability,positiontheboom,feed,androckdrill:
1.
BoomliftcylindermaximumOUT.
2.
BoomextensionmaximumIN.
3.
FeeddumpcylindermaximumOUT(makesurethatthefeeddoesnotcollidewiththe
liftingequipment).
4.
RockdrillinENDPOSITION(lowerposition).
5.
Makesurethatthehydraulicjackisretracted.
6.
TrackoscillationcylinderstoLOCKEDposition.
7.
Makesurethatnoneofthehoses,controls,oranyothercomponentscangetcaught
orsustaindamagewhenthehoistingslingsaretensionedandunderload.
8.
Placethehoistingslingsatdesignatedpointsunderbothcrawlertracks.
9.
Makesurethechassisisnotdamagedwhenpositioningthefeedinthetransport/
hoistingposition.
