MP-1xx SIP
MP-1xx SIP User’s Manual 158 Document #: LTRT-65404
8.7 Call Detail Report
The Call Detail Report (CDR) contains vital statistic information on calls made by the gateway.
CDRs are generated at the end and (optionally) at the beginning of each call (determined by the
parameter ‘CDRReportLevel
’). The destination IP address for CDR logs is determined by the
parameter ‘CDRSyslogServerIP’.
The following CDR fields are supported:
Table
8-2: Supported CDR Fields
Field Name Description
Cid Port Number
CallId H.323/SIP Call Identifier
Trunk N/A
BChan N/A
ConId H.323/SIP Conference ID
TG Trunk Group Number
EPTyp Endpoint Type
Orig Call Originator (IP, Tel)
SourceIp Source IP Address
DestIp Destination IP Address
TON Source Phone Number Type
NPI Source Phone Number Plan
SrcPhoneNum Source Phone Number
TON Destination Phone Number Type
NPI Destination Phone Number Plan
DstPhoneNum Destination Phone Number
DstNumBeforeMap Destination Number Before Manipulation
Durat Call Duration
Coder Selected Coder
Intrv Packet Interval
RtpIp RTP IP Address
Port Remote RTP Port
TrmSd Initiator of Call Release (IP, Tel, Unknown)
TrmReason Termination Reason
Fax Fax Transaction during the Call
InPackets Number of Incoming Packets
OutPackets Number of Outgoing Packets
PackLoss Number of Outgoing Lost Packets
UniqueId unique RTP ID
SetupTime Call Setup Time
ConnectTime Call Connect Time
ReleaseTime Call Release Time
RTPdelay RTP Delay
RTPjitter RTP Jitter
RTPssrc Local RTP SSRC
RemoteRTPssrc Remote RTP SSRC
RedirectReason Redirect Reason
TON Redirection Phone Number Type
NPI Redirection Phone Number Plan
RedirectPhonNum Redirection Phone Number
