MP-1xx SIP

MP-1xx SIP User’s Manual 82 Document #: LTRT-65404

Table 5-14: Reasons for Alternative Routing ini File Parameter

Parameter Name in ini File Parameter Format

AltRouteCauseTel2IP

AltRouteCauseTel2IP = <SIP Call failure reason from IP>

For example:

AltRouteCauseTel2IP = 408 (Response timeout).

AltRouteCauseTel2IP = 486 (User is busy).

Note: This parameter can appear up to 4 times.

AltRouteCauseIP2Tel

AltRouteCauseIP2Tel = <Call failure reason from Tel>

For example:

AltRouteCauseIP2Tel = 3 (No route to destination).

AltRouteCauseIP2Tel = 17 (Busy here).

Note: This parameter can appear up to 4 times.
