3 Technical specifications
3
3.1 Homologations
3.1.1 Directives
This product has been manufactured and put into circulation in accord
ance with the requirements and standards of the following European Di
rectives:
Gas Directive 2009/142/EC
Pressure Equipment Directive 97/23/EC, Article 3, paragraph 3
Electromagnetic Compatibility Directive 2004/108/EC
Generic standards: EN 61000-6-3, EN 61000-6-1
Standard referred to: EN 55014
For appliances connected to the electricity network:
Abide by the prevailing regulations for low voltage electrical appliances.
Low Voltage Directive 2006/95/EC
Generic standard: EN 60335–1
Standard referred to: EN 60335–2–102
Efficiency Directive 92/42/EC
Apart from the legal provisions and Directives, the additional Directives de
scribed in these instructions must also be observed.
For all provisions and Directives referred to in these instructions, it is
agreed that all addenda or subsequent provisions will apply at the time of
installation.
We hereby certify that the series of appliances specified below complies
with the standard model described in the CE declaration of conformity.
CE number CE-0085CP0089
NOx classification Class 5
Type of flue gas connection
B
23
– B
23P
C
13
C
33
C
43
C
53
C
63
C
83
Tab.1 General
Boiler speed Unit
POWER
HT+ 1.50
POWER
HT+ 1.70
POWER
HT+ 1.90
POWER HT
+ 1.110
Useful output at 80/60°C
Heating mode
Minimum kW 5.0 7.2 9.4 11.4
Useful output at 80/60°C
Heating mode
Maximum kW 45 65 85 102
Useful output at 50/30 °C
Heating mode
Minimum kW 5.4 7.8 10.2 12.3
Useful output at 50/30 °C
Heating mode
Maximum kW 48.6 70.2 91.8 110.2
Heating flow rate - Hi
Heating mode
Minimum kW 5.1 7.4
9.7
(1)
11.7
Heating flow rate - Hi
Heating mode
Maximum kW 46.3 66.9 87.4 104.9
3 Technical specifications
7609474 - v02 - 04092014 11
