6.5.5 Lengths of the air/flue gas pipes
Note
For configurations B
23
and C
93
, the lengths given in the tables are
valid for horizontal pipes with a maximum length of 1 metre. For
each additional metre of horizontal pipe, subtract 1.2 m from the
vertical length L
max
.
Tab.16 Maximum length
Configura
tion
Unit POWER HT+ 1.50 POWER HT+ 1.70 POWER HT+ 1.90 POWER HT+ 1.110
mm Ø 80 Ø 125 Ø 80 Ø 125 Ø 110 Ø 160 Ø 110 Ø 160
1 m L<10 m L<10 m L<10 m L<10 m L<10 m L<10 m L<10 m L<10 m
2 m L<10 m L<10 m L<10 m L<10 m L<10 m L<10 m L<10 m L<10 m
3 m L<9 m L<9 m L<9 m L<9 m L<9 m L<9 m L<9 m L<9 m
4 m L<9 m L<9 m L<9 m L<9 m L<9 m L<9 m L<9 m L<9 m
5 m L<10 m L<10 m L<10 m L<10 m L<10 m L<10 m L<10 m L<10 m
6 m L<10 m L<10 m L<10 m L<10 m L<10 m L<10 m L<10 m L<10 m
7 m L<8 m L<8 m L<8 m L<8 m L<8 m L<8 m L<8 m L<8 m
8 m L<9 m L<9 m L<9 m L<9 m L<9 m L<9 m L<9 m L<9 m
9mL
1
+ L
2
<60 m
L
1
<15 m
–L
1
+ L
2
<27
m
L
1
<15 m
L
2
<20 m
–L
1
+ L
2
<27 m
L
1
<7 m
–L
1
+ L
2
<27
m
L
1
<7 m
–
6 Installation
46 7609474 - v02 - 04092014
