Baxi POWER HT+ Series Installation And Service Manual

5
5.6 Connecting diagrams
Fig.27 Connection example with a domestic hot water tank
MW-3000022-01
T
34
1a
119
2a
1
2
31
26
24
33
25
1
Boiler flow
2
Heating pump
24
Domestic hot water tank exchanger primary inlet
25
Primary exchanger outlet domestic hot water tank
26
DHW load pump
31
Independent domestic hot water tank
119
Boiler return
5 Before installation
30 7609474 - v02 - 04092014
