Physician Manual
91098825-02 44 of 337
Properly Aligning the Charger
1. Press the power button. The indicator light will come on again, and the Charger
will begin beeping steadily to signal that it is searching for the Stimulator.
2. Place the Charger on the chest in the area of the Stimulator.
3. Position the Charger over the Stimulator.
The beeping will stop when the Charger is partially aligned with the Stimulator,
but the Charger should be fully aligned with the Stimulator for optimal
charging. Charging time may increase if the Charger is not fully aligned with the
Stimulator. To fully align the Charger over the Stimulator, position the bottom
curve of the Charger approximately 1 cm lower than the bottom curve of the
Stimulator, as shown below.
You may use the tips of your index and middle ngers to help locate the
Stimulator under the skin. Lay your ngers gently on the skin without applying
pressure or gripping. You may use this method to locate the center of the
Stimulator.
