EMBROIDERING TUTORIAL
33
2
Installing the bobbin
a
Insert the bobbin into the bobbin case.
b
Pass the thread through the thread slit and
under the tension-adjusting spring.
1 Thread slit
2 Tension-adjusting spring
c
Pull the thread about 50 mm (2 inches)
through the opening in the tension-
adjusting spring.
1 About 50 mm (2 inches).
Installing the bobbin case
a
Insert the bobbin case into the hook.
Insert the bobbin case while aligning the tab on the
bobbin case with the notch in the hook, as shown in
the illustration.
1 Tab
2 Notch
b
Fully insert the bobbin case until it snaps
into place.
c
Close the hook cover.
• Check that the thread winds off the bobbin
clockwise as shown in the illustration. If the
bobbin is installed with the thread winding
off in the opposite direction, the machine
will not embroider correctly.
