Canon 1318C002 User Manual

98
Lens Unit LX-IL07WF
Lens Type Short xed
lens
Throw Ratio 0.76 : 1
Image Size Projection
Distance (B)
Diagonal Width Height (A)
N/A
(inch) (m) (inch) (m) (inch) (m) (inch) (m)
40 1.02 34 0.86 21 0.54 25.1
0.64
50 1.27 42 1.08 26 0.67 31.8
0.81
60 1.52 51 1.29 32 0.81 38.5
0.98
80 2.03 68 1.72 42 1.08 52.0
1.32
100 2.54 85 2.15 53 1.35 65.5
1.66
120 3.05 102 2.58 64 1.62 78.9
2.01
150 3.81 127 3.23 79 2.02 99.1
2.52
180 4.57 153 3.88 95 2.42 119.3
3.03
200 5.08 170 4.31 106 2.69 132.8
3.37
300 7.62 254 6.46 159 4.04 200.1
5.08
400 10.16 339 8.62 212 5.38 267.4
6.79
500 12.70 424 10.77 265 6.73 334.8
8.50
* The table indicates projection range, optical performance is only guaranteed from 50 to 300 inches.
Lens Series
Part
Number
Lens Name F Number Focal Length Zoom
Ratio
Screen Size Throw Ratio
WUXGA 16:10 XGA 4:3
LX-IL01UW Ultra wide zoom lens 1.96-2.3 11.3-14.1mm 1.25:1 40”-500” 0.75-0.93:1 0.77-0.97:1
LX-IL02WZ Wide zoom lens 1.85-2.5 18.7-26.5mm 1.41:1 40”-500” 1.25-1.79:1 1.30-1.85:1
LX-IL03ST Standard zoom lens 1.7-1.9 26-34mm 1.3:1 40”-500” 1.73-2.27:1 1.79-2.35:1
LX-IL04MZ Middle zoom lens 1.86-2.48 32.9-54.2mm 1.65:1 40”-500” 2.22-3.67:1 2.30-3.81:1
LX-IL05LZ Long zoom lens 1.85-2.41 52.8-79.1mm 1.5:1 40”-500” 3.58-5.38:1 3.71-5.51:1
LX-IL06UL Ultra long zoom lens 1.85-2.48 78.5-121.9mm 1.55:1 40”-500” 5.31-8.26:1 5.50-8.56:1
LX-IL07WF Short xed lens 1.85 11.6mm - 40”-500” 0.76:1 0.79:1
* The table indicates projection range, optical performance is only guaranteed from 50 to 300 inches.
