92
Specications
RS-CL15
Adjustment range
Horizontal projection angle
5° leftward or rightward
V
ertical projection angle
5° upward or 20° downward
Screen slant angle
± 5°
Outer dimension of assembly
(excluding projection) (W x D x H)
460 x 490 x 152.6 mm (18.1 x 19.3 x 6.0 in)
Weight (Ceiling attachment only)
6.9 kg (15.2 lbs)
97
99
Table of Contents
