31
Precaution for Installing the Projector
The high quality display from the project is only available when the projector is correctly installed.
Generally, the light source facing the screen should be reduced or eliminated as much as possible. The
contrast of the image will be obviously reduced if the light directly shines on the screen, such as the
beam from windows or the other lighting illumination on the image. The image may become faded and
not bright.
Projector Installation and Setup
The available installation options are available as follows:
■ Front Table: Install the projector on the table and project the image forward.
■ Rear Table: Install the image behind the screen and project onto the screen.
■ Front Ceiling: Mounting the projector on the ceiling and project the image forward.
■ Rear Ceiling: Mounting the projector on the ceiling behind the screen and project onto the screen.
Cautions for Ventilation
The product is a high-brightness projector. The intake are located on the front and right sides to
provide sufcient air for cooling. The projector has two vents on the back for cool air discharging. When
installing, make sure the intake and outlet vents meet the required clearance to allow for the proper
cooling requirements of the system. At least 30cm around the intake and 50cm around the vent should
be clear.
30 cm/11.8"
Or Greater
30 cm/11.8"
Or Greater
50cm/19.68"
Or Greater
Note:
■ Inadequate cooling may cause the projector to stop operations due to overheating.
■ Overheating may shorten the life of components or laser.
■ The intake and outtake vents should not be obstructed to prevent overheating.
