Views of Projector Parts
Front View
123 4578910 55 6
Item Label Description
1 Terminals Use to connect to other devices.
2 Kensington Lock Secure to permanent object with a Kensington
®
Lock system.
3 Control Panel Use buttons to select or adjust the settings of the projector.
4 Power Panel Insert power cord to supply electrical power or select the input
voltage. See “Voltage Selection” on page 6.
5 Adjusting Foots There are 4 adjust foots for adjust the levelness of projection angle.
6 Air Intake Vent Take in air to cool the projector.
7 Front IR Receiver Receives IR signal from remote control.
8 LED Indicators Shows the status of the projector.
9 Lens Release Button Push to change the projector lens.
10 Lens Projection lens. (Optional)
