Horizontal Lens Shift
The image can be shifted horizontally to the right or left by 10% (0.1H) without moving the projector.
H
0.1H
0.1H
Lens Center
V
Max. 0.5V
■ The above lens shift range is for LX-IL02WZ (wide zoom lens), LX-IL03ST (standard zoom lens),
LX-IL04MZ (middle zoom lens), LX-IL05LZ (long zoom lens), LX-IL06UL (ultra long zoom lens).
■ The LX-IL07WF (short xed lens), optical performance guaranteed range is limited at 0% position.
Lens Shift Specication Vertical Horizontal
Up Down Left Right
Lens Shift Adjust Range 60% 30% 10% 20%
Optical performance guaranteed
range
50% 0% 10% 10%
