[16] Internal view of the stacker/stapler and saddle-stitch unit (Saddle Finisher-AM2 )
Description internal parts of stacker/stapler
1 Punch waste tray, to collect the punch waste.
2 Staple waste tray, to collect the staple waste.
See for specifications:
Finishing and delivery specifications
on page 274
Finishing for your output
on page 23
Professional stacker / stapler
44 Chapter 2 - Explore the print system
imagePRESS C800 Series
