4.4 - Physical data 30XB with option 254 or 255
30XB 250 to 800 with option 254 or 255
30XB option 254/255 250 300 350 400 450 500 600 700 750 800
Sound levels
Standard unit
Sound power
(1)
dB(A) 99 99 99 99 101 99 101 99 103 103
Sound pressure at 10 m
(2)
dB(A) 67 67 67 67 69 67 68 67 70 70
Unit + option 15
(3)
Sound power
(1)
dB(A) 93 93 94 95 95 95 97 96 97 98
Sound pressure at 10 m
(2)
dB(A) 61 61 62 63 63 63 65 63 64 65
Unit + option 15LS
(3)
Sou nd power
(1)
dB(A) 87 87 87 90 91 91 93 92 94 94
Sound pressure at 10 m
(2)
dB(A) 55 55 55 58 59 59 60 59 61 61
Unit + option 15LS+
(3)
Sound power
(1)
dB(A) - - - - 89 89 91 90 91 92
Sound pressure at 10 m
(2)
dB(A) - - - - 56 56 57 56 58 58
Dimensions
Standard unit
Length mm 3604 3604 4798 4798 4798 5992 7186 7186 8380 8380
Width mm 2253 2253 2253 2253 2253 2253 2253 2253 2253 2253
Height mm 2322 2322 2322 2322 2322 2322 2322 2322 2322 2322
Operating weight
(4)
Standard unit kg 3230 3272 3658 3931 3994 4477 5205 5314 6005 6294
Unit + option 15
(3)
kg 3475 3517 3899 4200 4263 4741 5494 5599 6286 6575
Compressors 06T semi-hermetic screw compressor, 50 r/s
Circuit A 1 1 1 1 1 1 1 1 1 1
Circuit B 1 1 1 1 1 1 1 1 1 1
No. of control stages
Refrigerant for standard unit
(4)
R134a
Circuit A
kg 60 64 70 85 85 102 102 100 129 112
teqCO
2
85,8 91,5 100,1 121,6 121,6 145,9 145,9 143,0 184,5 160,2
Circuit B
kg 64 64 56 56 56 56 88 95 88 95
teqCO
2
91,5 91,5 80,1 80,1 80,1 80,1 125,8 135,9 125,8 135,9
Oil
Circuit A l 20,8 20,8 20,8 23,5 23,5 23,5 23,5 23,5 27,6 27,6
Circuit B l 20,8 20,8 20,8 20,8 20,8 20,8 23,5 23,5 23,5 23,5
(1) in dB ref=10
-12
W, ‘A’ weighted. Declared dual-number noise emission values in accordance with ISO 4871 with an associated uncertainty of +/-3dB(A). Measured in
accordance with ISO 9614-1 and certied by Eurovent.
(2) In dB ref 20μPa, ‘A’ weighted. Declared dual-number noise emission values in accordance with ISO 4871 with an associated uncertainty of +/-3dB(A). For information,
calculated from the sound power Lw(A).
(3) Options : 15 = Low noise, 15LS = Very Low noise, 118a = DX freecooling option, 50= Heat recovery.
(4) Values are guidelines only. Refer to the unit name plate.
Eurovent certied values
