– 285 –
15-5. Flo w Selector unit
RBM-Y0383FUL, RBM-Y0613FUL
Location
No.
Part No. Description RBM-Y0383FUL RBM-Y0613FUL
1
1
2
3
4
5
6
7
43149418
43149417
4316V338
43146716
4314N088
43F60029
43135013
43135017
BODY ASSY, SERVICE
BODY ASSY, SERVICE
PC BOARD ASSY, MCC-1431
COIL, SOLENOID, VPV
COIL, SOLENOID, SR53
FILTER,NOISE
CABLE ASSY, POWER
CABLE ASSY
1
1
3
1
1
1
1
1
1
4
1
1
1
1
