– 34 –
3-4. Outdoor Inverter
460V model: MMY-MAP
∗∗∗
4FT6UL
No. Name Model Specification
MMY-MAP
1 Power supply terminal block HP-T3015-31-3P-L3S AC600V/100A,3P
096 120072
2 —Relay terminal block for reactor JXO-6B AC250V/20A,6P
3 Communication terminal block JXO-B2H AC30V (or no more then DC42V)
4 Reactor (For comp.) CH-79 5.8mH/16A
5 Reactor (For fan) CH-55 5.8mH/14A
6 P. C.board (Noise filter) MCC-1625 —
7 Line filter — 2.7mH/35A
8 P. C.board (I/F board) MCC-1606 —
9 P. C.board (IPDU for comp.) MCC-1596 —
10 Fuse (MCC-1596) GAC1 31.5A 31.5A/AC500V (P. C.board)
11 Comp. motor drive IPM (MCC-1596) PS22A76 25A/DC1200V (P. C.board)
14 Fan motor drive IPM (MCC-1610) FSBB20CH60C 20A/DC600V (P. C.board)
12 P. C.board (IPDU for fan) MCC-1610 —
15 Magnet contactor FC-1SUL AC220-240V
16 PTC thermistor MZ32-101RMARD01E 13A/AC500V
17 Pipe temp. sensor (TD) —
–22˚F to 275˚F (–30˚C to 135˚C)
(Ambient temp. range)
21 Oil temp. sensor (TK) —
–22˚F to 275˚F (–30˚C to 135˚C)
(Ambient temp. range)
18 Pipe temp. sensor (TS) —
–4˚F to 176˚F (–20˚C to 80˚C)
(Ambient temp. range)
19 Heatexchanger temp. sensor (TE) —
–4˚F to 176˚F (–20˚C to 80˚C)
(Ambient temp. range)
20 Outside temp sensor (TO) —
–4˚F to 176˚F (–20˚C to 80˚C)
(Ambient temp. range)
22 Liquid temp. sensor (TL) —
–4˚F to 176˚F (–20˚C to 80˚C)
(Ambient temp. range)
13 Fuse (MCC-1610) CES15 15AF924 15A/AC250V (P. C.board)
To Next Page
