– 33 –
3-3. Outdoor Inverter
208/230V model: MMY-MAP
∗∗∗
4FT9UL
No. Name Model Specification
MMY-MAP
1 Power supply terminal block HP-T3015-31-3P-L3S AC600V/100A,3P
096 120072
2 Relay terminal block for power supply JXO-6003 AC600V/60A,3P
3 Relay terminal block for power supply JXO-6003 AC600V/60A,3P
4
—
—Relay terminal block for reactor JXO-3006 AC600V/30A,6P
5 Communication terminal block JXO-B2H AC30V (or no more then DC42V)
6 Reactor (For comp.) CH-80 1.4mH/25A
7 Reactor (For fan) CH-55 5.8mH/14A
8 P. C.board (Noise filter) MCC-1608 —
9 Line filter — 0.9mH/AC500V/65A
10 P. C.board (I/F board) MCC-1606 —
11 P. C.board (IPDU for comp.) MCC-1595 —
14 P. C.board (IPDU for fan) MCC-1610 —
12 Fuse (MCC-1595) CES15 30AF924 30A/AC250V (P. C.board)
15 Fuse (MCC-1610) CES15 15AF924 15A/AC250V (P. C.board)
16 Fan motor drive IPM (MCC-1610) FSBB20CH60C 20A/DC600V (P. C.board)
17 Pipe temp. sensor (TD) —
–22˚F to 275˚F (–30˚C to 135˚C)
(Ambient temp. range)
21 Oil temp. sensor (TK) —
–22˚F to 275˚F (–30˚C to 135˚C)
(Ambient temp. range)
18 Pipe temp. sensor (TS) —
–4˚F to 176˚F (–20˚C to 80˚C)
(Ambient temp. range)
19 Heatexchanger temp. sensor (TE) —
–4˚F to 176˚F (–20˚C to 80˚C)
(Ambient temp. range)
20 Outside temp sensor (TO) —
–4˚F to 176˚F (–20˚C to 80˚C)
(Ambient temp. range)
22 Liquid temp. sensor (TL) —
–4˚F to 176˚F (–20˚C to 80˚C)
(Ambient temp. range)
13 Comp. motor drive IPM (MCC-1595) PS21A79 50A/DC600V (P. C.board)
To Next Page
