No. Parts Name Model Specification
MMY-MAP
072 096 120
1 Compressor DA421A3FB-29M1 Output: 2.3kW × 2 — —
Output: 2.1kW × 3 — —
Output: 2.7kW × 3 — —
3 PMV coil HAM-MD12TF-6 DV12V
15 Fan motor STF-340A1000-1 DC280V/1kW
16 Case heater (For comp.) AC240V/29W
17 Case heater (For accum.) AC240V/55W
18 Fusible plug 163.4˚F (73˚C)
8 2-way valve VPV-603DQ2 SV3B
4 2-way valve coil VPV-MOAQ1843A0 AC208 ~ 230V, 60Hz
12 High-pressure SW ACB-4UB3 OFF : 540psi (3.73MPa)
ON : 420psi (2.9MPa)
13 Pressure sensor
(For high pressure)
NSK-BC038F-U22 0.5~4.3V/0~540psi (3.73MPa)
14 Pressure sensor
(For low pressure)
NSK-BC010F-U22 0.5~3.5V/0~142psi (0.98MPa)
SV2
SV3A
SV3B
SV3C
2 4-way valve coil STF-01AQ1839UA1 AC208 ~ 230V, 60Hz
5 2-way valve coil FQ-D640 AC208 ~ 230V, 60HzSV41
SV42
SV43 —
SV5
SV3D
SV3E
SV3F —
SV6
9 2-way valve FDF3A06 SV41
SV42
SV43
6 2-way valve coil SR53 AC200L1500 AC208 ~ 230V, 60HzSV11
SV14
7 2-way valve VPV-303DQ1 SV3E
SV3F
—
—
10 2-way valve VPV-122DQ1 SV2
SV3A
SV3C
SV3D
SV3E
SV6
11 2-way valve SR53-04WR BA SV11
SV14
SV5
—
——
3-2. Outdoor Unit
(460V model: MMY-MAP
∗∗∗
4FT6UL)
