7-3. Applied Control Using Optional Board for Outdoor Unit
Optional control P.C. boards provide access to a range of functions as listed below.
No. Function
Outdoor unit
for control
P.C. board
connection
Control P.C. board to be used Outdoor unit interface P.C. board setting*
—
9
Header unit
1
Power peak-cut Control (Standard) — CN513(blue) SW07 1 —
—
9
Header unit
Power peak-cut Control (For one
input function)
— CN513(blue) SW07 1 J16
9
—Header unit
6
Operation Mode Selection Control — CN510(white) — — —
9
—Header unit
Operation Mode Selection Control
(forced choice)
— CN510(white) — — J01
—
9
Header unit2
Power peak-cut Control (Enhanced
Functions)
— CN513(blue) SW07 1.2 —
9
—Header unit5
Night operation (sound reduction)
Control
— CN508(red) — — —
——Compressor Operation Output8
Individual
outdoor unit
9
CN514(green) — — —
9
—Header unit3 Snowfall Fan Control — CN509(black) — — —
——Header unit7 Error / Operation output
9
CN511(green) — — —
——Header unit9 Operating Rate Output
9
CN514(green) SW16 1 —
9
—Header unit4 External master ON / OFF Control — CN512(blue) — — —
PCDM4UL PCMO4UL PCIN4UL Connector No. DIP SW No. Bit
Jumper to be
removed
Connector layout
DIP switch layout
Interface P.C. Board
Jumper wire layout
Layout of Outdoor Unit Interface P.C. Board
* DIP switch settings and jumper wire statuses vary from function to function.
