chapter 5000
page 72
1,2 - 2,0 t A.C.
SERVICE MANUAL
Electric
036-0410-07
DESCRIPTION OF THE CONSOLE STANDARD MENU
DUAL AC2 TRACTION UNIT MASTER MENU
MAIN MENU
HEADING
PARAMETER
CHANGE
TESTER
SET MODEL
SET OPTIONS
ADJUSTMENTS
CONNECTED TO 3
MOTOR VOLTAGE %
FREQUENCY Hz
ENCODER Hz
SLIP VALUE Hz
CURRENT RMS A
TEMPERATURE °C
TEMPERATURE #1 not used
TEMPERATURE #2 not used
ACCELERATOR V
STEER ANGLE °
INTERNAL WHEEL CUTBACK %
FORWARD SWITCH ON-OFF
BACKWARD SWITCH ON-OFF
ENABLE SWITCH ON-OFF
SEAT SWITCH ON-OFF
CUTBACK SWITCH ON-OFF
CUTBACK SWITCH 3 ON-OFF
BRAKE SWITCH ON-OFF
EXCLUSIVE HYDRO ON-OFF
BRAKE PEDAL POT. not used
HAND BRAKE ON-OFF
VOLTAGE BOOSTER V
BATTERY VOLTAGE V
BATTERY CHARGE %
SET POT BRK MIN ....V
SET POT BRK MAX ....V
SET BATTERY TYPE 48/72/80/96
ADJUST BATTERY ....V
MAX STEER RIGHT ....V
MAX STEER LEFT ....V
SET STEER 0-POS 2.5V
SET STEER RIGHT ....V
SET STEER LEFT ....V
THROTTLE 0 ZONE ....%
THROTTLE X ZONE ....%
THROTTLE Y ZONE ....%
ADJUSTMENT #02 1-9
ADJUSTMENT #01 1-9
MAIN CONT VOLT ....V
AUX OUTPUT VOLT ....V
ACCELERATION DELAY 0-9
RELEASE BRAKING 0-9
INVERS. BRAKING 0-9
PEDAL BRAKING 0-9
SPEED LIMIT BRAK. 0-9
BRAKE CUTBACK 0-9
MAX SPEED FORW Hz
MAX SPEED BACK Hz
CUTBACK SPEED Hz
CUTBACK SPEED 2 Hz
CUTBACK SPEED 3 Hz
FREQUENCY CREEP Hz
MAXIMUM CURRENT 0-9
ACC. SMOOTH 1-1.5 Hz
INV. SMOOTH 0.4-1.5 Hz
STOP SMOOTH 5-20 Hz
AUXILIARY TIME Sec
HOUR COUNTER RUNNING/ KEY ON
BATTERY CHECK ON/OFF
HYDRO KEY ON ON/OFF
STOP ON RAMP ON/OFF
AUX INPUT #1 EXCLUSIVE HYDRO
OPTION #1
CUT BACK SPEED
PEDAL BRAKING ANALOG/DIGITAL
SET TEMPERATURE ANALOG/DIGITAL/
NONE
STEER TABLE OPTION #1
PROGRAM
VACC
STEER
TABLE
ALARMS
RESTORE
PARAMETER
SAVE
PARAMETER
VACC SETTING MIN/MAX
NOT AVAIBLE
CODE
h, N°, C°
