CESAB C3E150 User Manual

chapter B
page 3
1,2 - 2,0 t A.C.
SERVICE MANUAL
Electric
036-0410-07
OIL AND GREASE SPECIFICATIONS
TIGHTENING TORQUES
STANDARD TYRES
FOR NORMAL ENVIRONMENTS
PARTS INVOLVED
Hydraulic system, lifting and power
steering
Transmission reduction gears
Hydraulic brake system
Mast securing joints - sideshift unit -
steering joint - general lubrication
with grease nipples - Mast guides
FOR COLD CLIMATES AND
COLD-STORAGE CELLS
PARTS INVOLVED
Hydraulic system, lifting and power
steering
Mast securing joints - sideshift unit -
steering joint - general lubrication
with grease nipples - Mast guides
14 daNm
14 daNm
2,3 daNm
13,5 daNm
5 daNm
5 daNm
2,2 daNm
4,9 daNm
0,8÷1,2 daNm
20 daNm
WHEEL TORQUE
steering wheels
driving wheels
DRIVE UNIT TORQUE
electric motor securing
unit securing to frame
service brake delivery pipes screw
parking brake cable fixing screw
oil filling and draining cap
VARIOUS TORQUES
mast-securing U-bolts
jack collar self-locking nuts
counterweight locking screws
Type Size Air Truck
Pressure
(C)
FRONT 432x152 1,2-1,6L t
REAR 457x178 1,8-2,0 t
REAR 381x127 ALL
(SE)
FRONT 18x7-8 1,2-1,6L t
FRONT 200/50-15 1,8-2,0 t
REAR 16x6-8 ALL
(PN)
FRONT 18x7-8 10 bar ALL
type specifications q.ty
AGIP ARNICA 46 ISO-L-HV FZG 20 L
tests to stage 11
AGIP ATF II D GM DEXRON II 6137-M 0,22 L
GM DEXRON 6032-M
GM DEXRON ATF type A suffix A
AGIP BRAKE FLUID DOT 4 SAE J 1730-JAN 80 ---------
DOT 4 TYPE
MOBILGREASE SPECIAL Lithium base ASTM ---------
275-305 NLGI Nr.2
Dropping point 180°
type specifications q.ty
AGIP ARNICA 22 ISO-L-HV FZG 20 L
tests to stage 10
MOBILTEMP SHC 100 Thickening Infusible ASTM ---------
265-295 NLGI Nr.2
Dropping point >260°
